ID # 23552423

2023 Yamaha GRIZZLY 90 Armour Grey

Call for Price
Overview

Proven Off‑Road performance and Grizzly‑styling with a 90cc engine and CVT transmission, the Grizzly 90 is perfect for trail riders age 10 and up.With convenient features like electric start, a large comfortable seat, front and rear racks and full-size Grizzly styling, the Grizzly 90 is a perfect machine for young riders who want to start a new off-road adventure.

Specifications
Model
GRIZZLY 90
Year
2023
Sale Type
New
Manufacturer
Yamaha
Color
Armour Grey
Engine Size
90cc
highlights

CONFIDENCE-INSPIRING 90CC ENGINE 2023 Yamaha GRIZZLY 90 Armour Grey

Built to bring maximum fun to youth ATV riders through a low-maintenance 90cc engine.

Tuned to develop excellent low-to-mid range performance.

Features fully automatic CVT transmission with reverse, gated shifter and electric start with a back-up kickstart.

SCALED DOWN, NOT SCALED BACK 2023 Yamaha GRIZZLY 90 Armour Grey

The Grizzly 90 takes cues from the top-performing big bore Grizzly but is designed specifically for younger riders getting into the sport.

Accessible, confidence-inspiring performance with Grizzly family style.

Accessible, confidence-inspiring performance with Grizzly family style. 2023 Yamaha GRIZZLY 90 Armour Grey

Ergonomics are designed to fit a wide range of riders 10 years and up.

The Grizzly 90's tire and suspension package is designed to find traction and provide a comfortable ride in a wide variety of terrain.



features and benefits

ENGINE

  • Robust 90cc Engine
    • 90cc four-stroke SOHC engine
    • Tuned for excellent low-to-mid range performance
    • Air-cooled for simplicity, performance and long service life
    • Proven wet-sump lubrication
  • Push-button electric starting backed up by an auxiliary kick starter.
    • Electric starting makes learning to ride more fun
  • Automatic Transmission
    • Fully automatic, continuously variable transmission (CVT) means no shifting.
    • Handy and something younger riders will appreciate.
    • Standard reverse simplifies maneuvering the Grizzly 90 in tight spots
  • Compact and Durable Drivetrain
    • Engine power is transferred to the rear wheels via a tried-and-true O-ring chain
    • Optimized angle for superior rear shock performance
  • Modern, Reliable Electronics
    • The CDI system means reliable ignition performance and a sealed, maintenance-free battery helps to provide worry-free performance
    • Handlebar-mounted reverse and neutral indicators keep the rider informed in all situations
  • Spark arrestor equipped exhaust system.
    • Quiet design
    • "Cleanable" spark arrestor prevents stray sparks from exiting the exhaust
    • Heat shield protects young riders from hot components

CHASSIS

  • Adventure-Ready Chassis
    • Compact A-arm front suspension is tuned for light steering and comfortable ride quality offering 5" of travel.
    • Swingarm setup in the rear brings with it 5.7" of wheel travel, adding to the Grizzly 90's full-size look and feel.
  • Integrated Cargo Racks
    • Robust steel cargo racks front and rear both boast 11 lb. carrying capacity
    • Provide younger riders the ability to pack their own gear as they join the family on their next adventure
  • Renowned Grizzly Traction
    • Equipped with rugged, trail rated tires, the grizzly 90 is ready to go anywhere
    • 19" up front and 18" in the rear.
    • Maximize traction on a wide variety of terrain.
  • Big, Mud-Deflecting Fenders
    • The Grizzly 90 boasts full-coverage fenders just like its Grizzly sibling.
    • Enhances styling and protection for the ride from mud and trail debris.
  • Comfortable Accommodations
    • The Grizzly 90 is designed to be comfortable for a wide variety of riders aged 10 years or older
    • With its large and plush seat matched to wide floorboards, riders will enjoy years of riding as they hone their off-road riding skills

SAFETY FEATURES

  • Keyed ignition lets parents control use
  • Heat shields on exhaust protect young riders from hot components
  • Adjustable speed limiter screw on throttle housing restricts throttle lever movement to reduce acceleration & top speed.
  • 2-stage rpm limiter device limits engine rpm. As skills improve, the limiter can be removed & maximum engine rpm will increase from 4,900 rpm to 8,500 rpm making a significant difference in power & performance

features & specs

KEY FEATURE

  • Robust 90cc Engine
  • Automatic Transmission
  • Compact and Durable Drivetrain
  • Modern, Reliable Electronics
engine
ENGINE
Air-cooled, SOHC 4-stroke; 2 valves.
IGNITION
CDI.
STARTING
Electric & Kickstart
FINAL DRIVE
O-ring Chain Drive
LUBRICATION
Dry sump
DISPLACEMENT
90cc
TRANSMISSION
CVT; F, N, R
FUEL DELIVERY
13mm Carburetor
BORE AND STROKE
47.0mm x 51.8mm
COMPRESSION RATIO
9.2:1
ESTIMATED FUEL CONSUMPTION±
33kpl / 93.2mpg (Imp.)
chassis
TIRES (REAR)
AT19 x 9-8
BRAKES (REAR)
Drum
TIRES (FRONT)
AT19 x 7-8
BRAKES (FRONT)
Dual Drum
SUSPENSION (REAR)
Monoshock swingarm; 5.7" travel
SUSPENSION(FRONT)
Single A-arm, 5" travel
critical data
WIDTH
1031.24mm (40.6")
HEIGHT
1005.84 (39.6")
LENGTH
1,562.1mm (61.5")
COLOUR(S)
Yamaha Blue Armour Grey
WHEELBASE
1031.24 (40.6")
WET WEIGHT
139.6 kg. (307.8 lb.)
SEAT HEIGHT
728.98mm (28.7")
FUEL CAPACITY
6.4 L (1.7 gal)
MAXIMUM GROUND CLEARANCE
100 mm (3.9")
